• Air conditioning, dual-zone manual climate control with individual climate settings for driver and right-front passenger
• Air conditioning, rear auxiliary
• Assist handles, front passenger and second row outboard
• Audio system feature, 8-speaker system
• Cruise control, electronic with set and resume speed
• Defogger, rear-window electric
• Door locks, power programmable with lockout protection
• Floor covering, color-keyed carpeting
• Floor mats, color-keyed carpeted first and second row, removable
• Headliner, cloth
• Heater, rear auxiliary with rear passenger heating ducts
• Lighting, interior with dome light, driver- and passenger-side door switch with delayed entry feature, cargo lights, door handle or Remote Keyless Entry-activated illuminated entry and map lights in front and second seat positions
• Mirror, inside rearview auto-dimming with 8-point compass and outside temperature display
• Steering wheel controls, mounted audio and cruise controls
• Steering wheel, leather-wrapped
• Theft-deterrent system, vehicle, PASS-Key III
• Tire Pressure Monitoring System (does not apply to spare tire)
• Visors, driver and front passenger illuminated vanity mirrors, padded with cloth trim, extends on rod
• Warning tones, headlamp on, key-in-ignition, driver and right-front passenger safety belt unfasten and turn signal on
• Windows, power with driver Express-Down and lockout features
• XM Satellite Radio (subscription required)

• Alternator, 160 amps
• Battery, heavy-duty 600 cold-cranking amps, maintenance-free with rundown protection and retained accessory power
• GVWR, 7100 lbs. (3221 kg) (Standard on 2WD models.)
• Rear wheel drive
• Steering, power
• Suspension, front coil-over-shock with stabilizer bar
• Suspension, rear multi-link with coil springs
• Trailering equipment, heavy-duty, includes trailering hitch platform, 7-wire harness with independent fused trailering circuits mated to a 7-way sealed connector and (VR4) 2" trailering receiver

• Air bags, dual-stage frontal, driver and right-front passenger with Passenger Sensing System (right-front passenger air bag status on overhead console) (Always use safety belts and the correct child restraints for your childs age and size. Even in vehicles equipped with air bags and the Passenger Sensing System, children are safer when properly secured in a rear seat. Never place a rear-facing infant restraint in the front seat of any vehicle equipped with an active frontal air bag. See the vehicles Owners Manual and child safety seat instructions for more safety information.)
• Air bags, head curtain side-impact, first and second row outboard seating positions with rollover sensor, includes third row seating positions with (AS3) 3-passenger third row 50/50 split-bench seat or (AW2) 2-passenger third row 50/50 split-bench seat (Head curtain side air bags are designed to help reduce the risk of head and neck injuries to front and rear seat occupants on the near side of certain side-impact collisions. Always use safety belts and the correct child restraints for your childs age and size, even in vehicles equipped with air bags. Children are safer when properly secured in a rear seat. See the vehicles Owners Manual and child safety seat instructions for more safety information.)
• Brakes, 4-wheel antilock, 4-wheel disc, VAC power
• LATCH system (Lower Anchors and Top tethers for CHildren), for child safety seats
• OnStar Equipped (subscription required)
• Safety belts, 3-point, driver and right-front passenger
• StabiliTrak, stability control system with Proactive Roll Avoidance

TRANSMISSION, 4-SPEED AUTOMATIC, ELECTRONICALLY CONTROLLED

• with overdrive and tow/haul mode (STD)

REAR AXLE, 3.23 RATIO

• (STD)

SUSPENSION PACKAGE, PREMIUM SMOOTH RIDE

• (STD)

ENGINE, VORTEC 4.8L V8 SFI

• (295 hp [220.0 kW] @ 5600 rpm
• 305 lb-ft torque [411.8 N-m] @ 4800 rpm)
• iron block (STD)

SEATS, THIRD ROW 50/50 SPLIT-BENCH

• with 3-passenger
• removable
• all-belts-to-seat

SEATS, FRONT 40/20/40 SPLIT-BENCH WITH CUSTOM CLOTH

• 3-passenger
• includes (AG1) 6-way power driver seat adjuster
• (AM1) driver manual lumbar control
• driver and front passenger manual reclining
• center fold-down armrest with storage
• lockable storage compartments in seat cushion (includes auxiliary power outlet)
• adjustable outboard head restraints and storage pockets (STD)

LS PREFERRED EQUIPMENT GROUP

• Includes Standard Equipment

AUDIO SYSTEM, AM/FM STEREO WITH MP3 COMPATIBLE CD PLAYER

• seek-and-scan
• digital clock
• auto-tone control
• Radio Data System (RDS)
• speed-compensated volume
• TheftLock and auxiliary audio input jack (STD)

WHEELS, 4 - 17" X 7.5" (43.2 CM X 19.1 CM) ALUMINUM, 5-SPOKE

• with radial grooves

• Preferred Equipment Group 1LS
• 3.23 Rear Axle Ratio
• Heavy-Duty Rear Locking Differential
• 17 inch x 7.5 inch 5-Spoke Aluminum Wheels
• 40/20/40 Front Reclining Split-Bench Seat
• Custom Cloth Seat Trim
• 3rd Row 3-Passenger Cloth 50/50 Split-Bench Seat
• AM/FM Stereo w/XM Satellite
• Premium Smooth Ride Suspension Package
• 6-Way Power Driver Seat Adjuster
• Driver Manual Lumbar Control
• Power Heated Manual-Folding Outside Mirrors
• XM Satellite Radio
• 4-Wheel Disc Brakes
• Emergency communication system: OnStar Safe & Sound
• AM/FM radio: XM
• Front Center Armrest w/Storage
• Compass
• 8 Speakers
• Auto-dimming Rear-View mirror
• Front beverage holders
• Variably intermittent wipers
• Trip computer
• Traction control
• Tilt steering wheel
• Steering wheel mounted audio controls
• Split folding rear seat
• Speed control
• Security system
• Roof rack: rails only
• Remote keyless entry
• Rear window wiper
• Rear window defroster
• Rear seat center armrest
• Rear reading lights
• Rear anti-roll bar
• Rear air conditioning
• Radio data system
• Power windows
• Power steering
• Power driver seat
• Power door mirrors
• Passenger vanity mirror
• Passenger door bin
• Panic alarm
• Overhead console
• Overhead airbag
• Outside temperature display
• Occupant sensing airbag
• Low tire pressure warning
• Illuminated entry
• Heated door mirrors
• Fully automatic headlights
• Front wheel independent suspension
• Front reading lights
• Front dual zone A/C
• Front anti-roll bar
• Dual front impact airbags
• Driver vanity mirror
• Driver door bin
• Delay-off headlights
• CD player
• Bumpers: body-color
• Bodyside moldings
• Alloy wheels
• ABS brakes
• Voltmeter
• Tachometer
• Spoiler
• Electronic Stability Control
• Air Conditioning
• DIFFERENTIAL HEAVY-DUTY LOCKING REAR
• TRANSMISSION 4-SPEED AUTOMATIC ELECTRONICALLY CONTROLLED with overdrive and tow/haul mode (STD)
• REAR AXLE 3.23 RATIO (STD)
• TIRES P265/70R17 ALL-SEASON WHITE OUTLINED-LETTER
• EBONY CUSTOM CLOTH SEAT TRIM
• SUSPENSION PACKAGE PREMIUM SMOOTH RIDE (STD)
• ENGINE VORTEC 4.8L V8 SFI (295 hp [220.0 kW] @ 5600 rpm 305 lb-ft torque [411.8 N-m] @ 4800 rpm) iron block (STD)
• BLACK
• SEATS THIRD ROW 50/50 SPLIT-BENCH with 3-passenger removable all-belts-to-seat
• SEATS FRONT 40/20/40 SPLIT-BENCH WITH CUSTOM CLOTH 3-passenger includes (AG1) 6-way power driver seat adjuster (AM1) driver manual lumbar control driver and front passenger manual reclining center fold-down armrest with storage lockable storage compartments in seat cushion (includes auxiliary power outlet) adjustable outboard head restraints and storage pockets (STD)
• LS PREFERRED EQUIPMENT GROUP Includes Standard Equipment
• AUDIO SYSTEM AM/FM STEREO WITH MP3 COMPATIBLE CD PLAYER seek-and-scan digital clock auto-tone control Radio Data System (RDS) speed-compensated volume TheftLock and auxiliary audio input jack (STD)
• WHEELS 4 - 17" X 7.5" (43.2 CM X 19.1 CM) ALUMINUM 5-SPOKE with radial grooves
• Rear Wheel Drive
• Tow Hitch
• Power Steering
• Aluminum Wheels
• Tires - Front All-Season
• Tires - Rear All-Season
• Conventional Spare Tire
• Luggage Rack
• Running Boards/Side Steps
• Automatic Headlights
• Daytime Running Lights
• Automatic Headlights
• Heated Mirrors
• Power Mirror(s)
• Privacy Glass
• Intermittent Wipers
• AM/FM Stereo
• CD Player
• MP3 Capability
• Auxiliary Audio Input
• Satellite Radio
• Requires Subscription
• Power Driver Seat
• Cloth Seats
• Split Bench Seat
• Power Outlet
• Driver Adjustable Lumbar
• Floor Mats
• Pass-Through Rear Seat
• Rear Bench Seat
• Adjustable Steering Wheel
• Leather Steering Wheel
• Cruise Control
• Steering Wheel Audio Controls
• Tire Pressure Monitor
• Power Windows
• Power Door Locks
• Keyless Entry
• Power Door Locks
• Cruise Control
• Immobilizer
• Multi-Zone A/C
• A/C
• A/C
• Rear A/C
• Rear Defrost
• Power Outlet
• Auto-Dimming Rearview Mirror
• Driver Vanity Mirror
• Passenger Vanity Mirror
• Driver Illuminated Vanity Mirror
• Passenger Illuminated Visor Mirror
• Front Reading Lamps
• Rear Reading Lamps
• Traction Control
• Stability Control
• ABS
• 4-Wheel Disc Brakes
• Telematics
• Requires Subscription
• Driver Air Bag
• Passenger Air Bag
• Passenger Air Bag Sensor
• Front Head Air Bag
• Rear Head Air Bag

• Brakes
• Brake ABS System: 4-Wheel
• Brake Type: Pwr
• Disc - Front (Yes or ): Yes
• Disc - Rear (Yes or ): Yes
• Front Brake Rotor Diam x Thickness (in): 13.0 x 1.18
• Rear Brake Rotor Diam x Thickness (in): 13.5 x 0.79
• Cargo Area Dimensions
• Cargo Area Length : Floor to Console (in)
• Cargo Area Length : Floor to Seat 1 (in)
• Cargo Area Length : Floor to Seat 2 (in)
• Cargo Area Length : Floor to Seat 3 (in)
• Cargo Area Length : Floor to Seat 4 (in)
• Cargo Area Width : Beltline (in)
• Cargo Box (Area) Height (in): 41.7
• Cargo Box Width : Wheelhousings (in)
• Cargo Volume to Seat 1 (ft³): 108.9
• Cargo Volume to Seat 2 (ft³): 60.3
• Cargo Volume to Seat 3 (ft³): 16.9
• Cooling System
• Total Cooling System Capacity (qts): 14.4
• Electrical
• Cold Cranking Amps : 0° F (2nd)
• Cold Cranking Amps : 0° F (Primary)
• Maximum Alternator Capacity (amps): 160
• Exterior Dimensions
• Ground Clearance, Front (in): 10.5
• Ground Clearance, Rear (in): 9.1
• Ground to Top of Load Floor (in): 31.7
• Height, Overall (in): 76.9
• Length, Overall w/rear bumper (in): 202.0
• Wheelbase (in): 116.0
• Width, Max w/o mirrors (in): 79.0
• Frame
• Frame Type: Ladder
• Fuel Tank
• Fuel Tank Capacity, Approx (gal): 26
• Interior Dimensions
• Front Head Room (in): 41.1
• Front Hip Room (in): 64.4
• Front Leg Room (in): 41.3
• Front Shoulder Room (in): 65.3
• Passenger Capacity: 9
• Second Head Room (in): 39.2
• Second Hip Room (in): 60.6
• Second Leg Room (in): 39.0
• Second Shoulder Room (in): 65.2
• Third Head Room (in): 37.9
• Third Hip Room (in): 49.1
• Third Leg Room (in): 25.6
• Third Shoulder Room (in): 61.7
• Mileage
• EPA Fuel Economy Est - City (MPG): 14
• EPA Fuel Economy Est - Hwy (MPG): 19
• Steering
• Steering Ratio (:1), At Lock: 17.75
• Steering Ratio (:1), On Center: 17.75
• Steering Type: Pwr
• Turning Diameter - Curb to Curb (ft): 39.0
• Summary
• Body Code: E52
• Body Style: 4 Door
• Vehicle Name: Chevrolet Tahoe
• Suspension
• Axle Capacity - Front (lbs): 3200
• Axle Capacity - Rear (lbs): 4100
• Axle Ratio (:1) - Rear: 3.23
• Axle Type - Front: Independent
• Axle Type - Rear: Semi-floating
• Shock Absorber Diameter - Front (mm): 46.0
• Shock Absorber Diameter - Rear (mm): 46.0
• Spring Capacity - Front (lbs): 3250
• Spring Capacity - Rear (lbs): 4100
• Stabilizer Bar Diameter - Front (in): 1.41
• Stabilizer Bar Diameter - Rear (in): 1.1
• Suspension Type - Front: Coil springs
• Suspension Type - Rear: Coil springs
• Tires
• Front Tire Capacity (lbs): 2135
• Front Tire Order Code: QAS
• Front Tire Size: P265/70R17
• Rear Tire Capacity (lbs): 2135
• Rear Tire Order Code: QAS
• Rear Tire Size: P265/70R17
• Revolutions/Mile : 45 mph - Front
• Revolutions/Mile : 45 mph - Rear
• Revolutions/Mile : 45 mph - Spare
• Spare Tire Order Code: ZVL
• Spare Tire Size: P265/70R17
• Trailering
• Dead Weight Hitch - Max Tongue Wt. (lbs): 500
• Dead Weight Hitch - Max Trailer Wt. (lbs): 5000
• Wt Distributing Hitch - Max Tongue Wt. (lbs): 675
• Wt Distributing Hitch - Max Trailer Wt. (lbs): 4500
• Vehicle
• Rear Door Type: Liftgate
• Weight Information
• Curb Weight - Front (lbs): 2672
• Curb Weight - Rear (lbs): 2467
• Gross Axle Wt Rating - Front (lbs): 3200
• Gross Axle Wt Rating - Rear (lbs): 4100
• Gross Combined Wt Rating (lbs): 10000
• Gross Vehicle Weight Rating Cap (lbs): 7100
• Wheels
• Front Wheel Material: Aluminum
• Front Wheel Size (in): 17 x 17.5
• Rear Wheel Material: Aluminum
• Rear Wheel Size (in): 17 x 17.5
• Spare Wheel Material: Steel
• Spare Wheel Size (in): 17 x
